Customizable spiral conveyor belt

Flat spiral conveyor belt consists of a series of alternating single or double spiral wires, which can be round and flat, they can be added crimped or straight cross rods. And the alternating structure effectively reduces downtime. So flat spiral conveyor belt is an economic choice, it can provides a flat loading surface for small products or easily broken products.

Flat spiral conveyor belt can be made of stainless steel, copper steel and brass steel, different materials can be adapted to different applications to meet the needs of more customers.

Features：

1. Excellent strength to weight ratio but with maximum flexibility.

2. High temperature resistance, anti-corrosion and anti-rust, resistant to acid and alkaline.

3. Stable product conveying without slipping, griping and jamming, good air circulation.

4. Side board can be added to prevent products from falling down to the ground.

5. Complying with food safety standards such as FDA, GMP and others up your request.

6. Durable, low maintenance cost, quick and easy install and replacement.

• Material：Stainless steel 304, 314, 316, 316L, carbon steel, copper steel, brass steel and other types are available.

• Surface treatment：Galvanized, 3% chromium plate, manganese plated.

• Spiral diameter：0.9–3.0 mm.

• Cross wire diameter：1.2–4.0 mm.

• Flat wire size (mm)：From 1 × 0.7 to 6 × 3.

• Spiral wire pitch：4–22 mm.

• Cross rod pitch：4–33 mm.

• Belt width：Up to 5 meters or more upon your request.

• Belt speed：0.5 m/min to 60 m/min.

• Edge type：Welded edge, hook edge, laddered edge, chain link edge.

According to customer requirements, provide different packaging.

1. Standard packing---Bulk. Save space, packaging costs, and shipping costs without using pallets.

2. Customized packing. The cost is high, but the loading and unloading is convenient, saving labor costs.

3. Custom labels.

Warehousing: Our factory has a large warehouse, which is clean and dry. A short-term storage screen service is available.
